Overview

The Framax PAST-FLASH 01000-SA is a semi-automatic flash pasteurizer with a capacity of 1,000 liters per hour. It enables precise heating at 75 °C with a holding time of 30 seconds and ensures efficient cooling to 2 °C.

Technical details

• Capacity: 1,000 l/h
• Pasteurization temperature: 75 °C, 30 seconds holding time
• Outlet temperature: 2 °C
• Hot water system: 78 °C inlet, 68 °C outlet
• Cooling system: Propylene glycol (-3 °C inlet, 2 °C outlet)
• Steam consumption: 20 kg/h at 3 bar
• Pump output:
  • 2.2 kW (product)
  • 1.5 kW (filling)
  • 0.37 kW (hot water)
• Compressed air supply: 8 bar external
• Electrical connection: 400V, 50Hz, 3-phase, 5 kW
• Dimensions: 2,500 x 1,100 x 1,700 mm (incl. buffer tank)
• Weight: 900 kg (incl. buffer tank)

Scope of delivery

• Three-stage plate heat exchanger made of stainless steel (AISI 316)
• Feed pump with inverter-controlled speed
• Flow meter with magnetic float device
• Thermoregulation system for precise temperature control
• Electromechanical control cabinet (IP66 protection class)
• Automatic venting and safety valves
• Buffer tank (optional, 300 L)
