Framax RLA-H06-S2-L2-D480 Self Adhesive Labeler (2014)
11,000 € (ExWorks)
Get an official quote
Get an official quote
Fill in the information below to receive an official quote on the machine you have selected.
Country:
Italy
Year:
2014
Category:
Labelling
Manufacturer:
Framax
Model:
RLA-H06-S2-L2-D480
Availability:
Immediately
SKU:
IT-LAB-FRA-2014-00001
Overview
This labeller was built in 2014 by Italian manufacturer Framax. It is an automatic rotary self-adhesive labelling machine for glass bottles with a capacity up to 4,000 bottles per hour.
Techn. Details
- Capacity: up to 4,000 bph (0,33l glass bottle, wrap-around label)
- 2 labelling stations
- Max. height of the paper passage 200 mm
- Max. speed of the output of the paper: 32 m/min.
- Max. roller outer diameter 300 mm
- Max label length 180mm
- Voltage: 400V, 50 Hz
- Stainless-steel pass-through conveyor belt (2.500 mm)
- Stop of the machine in case of container jam-up
- Low wear and noise levels due to alternated steel and zellamid transmission gears
- Self-adhesive labelling station speed variation automatically synchronized with the machine
- Photocell for paper stop automatic self-regulation for the read-out of the different label colours
- Photocell of presence of the container
- Controls panel board fitted on the head
- Adjustable articulated labels-detacher
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
