Overview

The Octopus film winder was built in Finland in 2010. The machine was in use at a mineral water company until recently and is already dismantled and immediately available.

Technical details

• Speed of the motion sequences
  • Ring up/down 0.15 m/s
  • Ring rotation 18 rpm
  • Film insertion 4.5 m/s
• Film: LLDE pre-stretched
• Hold-down device
• Pallet dimensions
  • ¼ EURO,
  • ½ EURO,
  • EURO,
  • 1200 × 1000,
  • Max. height 2400 mm,
  • Min. height approx. 50 cm depending on the system settings
• Dimensions
  • Length 2850 mm
  • Width 2150 mm
  • Height 3140 mm
  • Weight 1050 kg
• Voltage: 3 × 400 VAC 50 Hz +N+earth
• Air pressure 6 bar, 9 l/operating cycle
