Krones Linaflex Tunnel Pasteurizer (2013)

Country:

Germany

Year:

2013

Category:

Tunnel Pasteurizer

Manufacturer:

Krones

Model:

Linaflex

Availability:

Sold

SKU:

DE-TUN-KRO-2013-00001

Overview

The Linaflex tunnel pasteurizer was built in 2013 by the German manufacturer Krones. The machine has only a few operating hours, was still in use in 2023 and has been partially overhauled. The machine has already been dismantled, stored and is immediately available.

Technical data

  • Treatment area: 96 m²
  • Consumption
    • Maximum temperature of the drain water 80 °C
    • Steam - design flow rate 1,996 kW
    • Heat quantity 1st cooling medium 1,099 kW
    • Main water - design flow rate 47.6 m3/h
    • Air consumption 1 m3/h
  • Number of decks: 1
  • Total number of zones: 10
  • Number of pairs of regenerative zones: 3
  • Number of pasteurizing zones: 4
  • Number of tunnel modules (without inlet and outlet module): 10
  • Equipment
    • Main conveyor: Marathon Belt
    • Filter plug-in sieves
    • Material side doors: Stainless steel
    • Nozzle material: Plastic
    • Various extensions such as container sliding system, consumption measurement, dosing systems, machine insulation
    • Heating of the machine by means of plate heat exchanger incl. automatic temperature control
  • Dimensions
    • Width 5.230 m
    • Outer width incl. pumps and operating area 7.330 m
    • Total length without operating platforms 20.606 m

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
