Overview

This dual-lane automatic fishfilet-skinner, type: Maja DFS 4365/PA was built in 2011 in Germany. The dual-lane skinner DFS 4365 has been designed for fully automatic skinning of fish fillets on two independently controlled skinning systems. Offering more flexibility to fish processors as two skinning styles can be performed at the same time, the machine capacity is increased by 50 %.(approx. 1,5 tons of salmon fillets / h). There is one belt but two knifeholders. That means you can run both sides filets sperately.

• Two independently controlled skinning systems which can be configurated according to the processors demand.
• Downward pressure on the product is provided by adjustable air-filled rollers guaranteeing effective yet smooth handling of the fillets.
• Water spray device can be switched on if necessary for rinsing away scales from the tooth roller.
• Guide rails for perfect infeed position of the fillets High ingress protection

Technical Details

• Cutting width 2 x 365 mm
• Width: 1383 mm
• Depth incl. Discharge belt: 1879 mm
• Height: 1208 mm
• Weight: 405 kg
• Electrical connection: 200-230 VAC, 380-460 VAC, 50 or 60 Hz
• Power consumption: 0,75 kW
• Fuse connection: 16 A
• Compressed air: 6 bar # 36l/min

Scope of delivery

• Automatic dual-lane skinner for fish filets | Maja | DFS 4365/PA | 2011
